How much do you know about the ITB?

March 4, 2018

If your first question is “what on earth is the ITB” then this post is definitely for you. Even if you feel you are all over it then you may be surprised there are a couple of quirky things about the ITB that people often overlook.





  1. Firstly the ITB or Iliotibial band is a band of connective tissue that runs down the side of your leg. It is notorious for being very painful to the touch, especially when getting it massaged or foam rolling it. It can also cause pain in the outside of the knee and hip and can be one of the most obvious causes of pain in this region. It often gets really tight from things like running, cycling and jumping as it works to stabilise the hip and knee. It can also tighten up from lots of sitting and inactivity as it is a hip flexor and if you sit all day you basically shorten up the front/side of your hips.


  2. The ITB is also known as the ITT or Iliotibial Tract (mostly Americans because they like to be different). More technically it is known as the Fascia Lata (not Latte). Fascia Lata basically means the lateral fascia. So the ITB is technically a thick band of fascia ( white connective tissue) on the outside of the leg. We have heard it incorrectly called the ITV or IBT. These are incorrect, but we know what they meant.


  3. The ITB is important for stabilising the hip and knee.


  4. The ITB is NOT a muscle. This is the most common myth you will hear about the ITB. Remember it is a band of fascia (the fascia lata). If you look at a muscular system poster or muscle anatomy book/app you will see that muscles are red (get lots of blood), whereas fascia, ligaments and tendons are white (not great blood supply).


  5. The ITB is really like a big tendon from 2 muscles and it can be broken into 2 parts. The anterior (front) part and the posterior (back) part. The TFL or Tensor Fascia Lata (anterior) and the Glute Maximus (posterior) . The Glute Max has lots of attachments at the origin (the part of the muscle that doesn’t move) such as the pelvis, sacrum and Gluteus medius. The Insertion (the part that moves is the ITB and the gluteal tuberosity. Depending on what you read, some anatomy books say that around 80% of the ITB attaches to the Gluteus Maximus. The TFL muscle attaches to the pelvis at the origin (the part that doesn’t move), the insertion attaches to the ITB. So you can see both the TFL and the Glute Max both become the ITB.


  6. So where does the ITB insert? The ITB inserts to place on the Tibia, just below the lateral knee joint called Gerdy's Tubercle. Just neat the lateral condyle of the Tibia, which is on the outside of the leg, just below the knee, in case you don’t know where the lateral condyle of the Tibial is. It also blends in with the insertion of the Vastus Lateralis which is the outside quad muscle and the connective tissue around the knee. From a fascia perspective the ITB also blends with the Tibialis Anerior and Peroneus Longus muscles becoming part of the lateral and spiral lines respectively. This shows that the ITB is heavily involved in lateral knee stability and also rotation of the tibia (lower leg bone) and knee joint.





  7. What does the ITB do? As it attaches to the TFL and Glute Max it does these actions. Most notably internal rotation of the hip, hip flexion, abduction of the hip (lifting your leg out to the side). It also provides lateral hip and knee stability, especially when the leg is straight or the knee is bent up to 30 degrees. Meaning your hips and knees don't move out to the side when you are walking, running, jumping or doing anything where you knee is under load such as squatting, getting out of a chair, walking up and down stairs and pretty much everything you do.


  8. Can you stretch the ITB? Well it depends who you ask. In one study they found that the ITB may only stretch as far as 2mm. That is not very much. And being quite elastic, even if you get that 2mm out of it, it will likely go straight back to where it was. The classic ITB stretch looks like a ballet type stretch (image on your right).



    This is a great side line stretch of the body and I think it should be performed by most people regularly to open up the side of the body as we side slumped most of the time. But this stretch wont have very much effect on the ITB. The reason is because there are certain areas of the body where it is really hard to take the attachments away from each other. This is the essence of any stretch. In the case of the ITB it has attachments at the TFL and Glute Max which have different ways to stretch them. And then the attachment at the tibia requires you to bend the knee to at least 30 degrees to put more tension on the ITB. Most people wont or cant bend their knee in this position whilst stretching their leg across the other side of their body. The closest thing you can get to this stretch is the OBERS test, which is a test for ITB tightness we do in clinic. So the best bet for stretching the ITB would be to have someone else stretch you on a massage table. The stretch below is one of the better ITB stretches you can do yourself. This stretch works to stretch the TFL component of the ITB mostly. Try not to over extend your lower back like it is in the photo as this will take some of the stretch off the TFL. The glute max wont be stretched in this position. Use the bottom leg to push the top leg down.

     This is a better stretch (below) for the Glute max component and the ITB in general. Click the link to go to the video. You have to lie on a bench with the leg you are going to stretch off the bench with the knee bent. Tuck your bum under to flatten your lower back, internally rotate the foot inwards and also pull the toes towards your body (don't point them). Raise your arms above your head. This doesn't really seem like an ITB stretch if you are used to the ballet style stretch, but if you try it you will see that it really does get into the knee. The key with any ITB stretch is to bend the knee. The ballet style stretch doesn't do this




  9. What can we do for a tight ITB? Well, the reality is that the ITB is supposed to be tight. Imagine the ITB is like a leather belt runnin
